Java Applets & Layout Managers



//First Program of applet



import java.applet.*;

import java.awt.*;



/*

                <applet code = "myapplet" width = 300 height = 400></applet>

*/

public class myapplet extends Applet

{

                public void paint(Graphics g)

                {

                                g.drawString("This is Applet", 100, 100);

                }

}

OUTPUT:


*******************************************************
//Drawshape in java

import java.applet.*;
import java.awt.*;

/*
<applet code = "rectangle" width = 500 height = 500></applet>
*/

public class rectangle extends Applet
{
public void paint(Graphics g)
{
g.drawRect(50, 50, 200, 200);
g.setColor(Color.blue);
g.fillRect(250, 250, 50, 50);
}
}
OUTPUT:


******************************************************
//Passing parameter to an appplet

import java.awt.*;
import java.applet.*;

/*
<applet code = "passing_parameter_in_applet.class" width = 400 height = 400>
<param name = "message" value = "Applete with parameter ">
<param name = "forebackground" value = "#fff00">
</applet>
*/

public class passing_parameter_in_applet extends Applet
{
String msg, fore;

public void init()
{
msg = getParameter ("message");
fore = getParameter("forebackground");
}
public void paint(Graphics g)
{
g.setColor(Color.decode(fore));

g.drawString(msg, 100, 100);
}
}
OUTPUT:

*******************************************************
//Applet Life Cycle
import java.applet.*;
import java.awt.*;
/*
<applet code = "Applet_Life_Cycle" width = 400 height = 400>
</applet>
*/

public class Applet_Life_Cycle extends Applet
{
String msg;

public void init()
{
msg  = "init";
}
public void start()
{
msg = "start";
}
public void paint(Graphics g)
{
msg += "paint";
g.drawString(msg, 20, 100);
}
public void stop()
{
msg += "Stop";
}
public void destoy()
{
System.out.println("destoy");
}
}
OUTPUT:


*******************************************************

//AWT Components



import java.awt.*;

import java.applet.*;



/*

<applet code = "awtcomponent.class" width = 400 height = 400></applet>

*/



public class awtcomponent extends Applet

{

                Label lbl1, lbl2;

                TextField txt1, txt2;

                Button btn1;



                public void init()

                {

                                lbl1 = new Label("Username");

                                add(lbl1);



                                txt1 = new TextField(10);

                                add(txt1);



                                lbl2 = new Label("Password");

                                add(lbl2);



                                txt2 = new TextField(10);

                                add(txt2);



                                btn1 = new Button("Log in");

                                add(btn1);

                }

}

OUTPUT:



*******************************************************

//swing component



import java.awt.*;

import javax.swing.*;



/*

<applet code = "swing_component.class" width = 400 height = 400></applet>

*/



public class swing_component extends JApplet

{

                Container con;

                JLabel lbl1, lbl2;

                JTextField txt1, txt2;

                JButton btn1;



                public void init()

                {

                                con = getContentPane();

                                con.setLayout(new FlowLayout());



                                lbl1 = new JLabel("Username");

                                con.add(lbl1);



                                txt1 = new JTextField(10);

                                con.add(txt1);



                                lbl2 = new JLabel("Password");

                                con.add(lbl2);



                                txt2 = new JTextField(10);

                                con.add(txt2);



                                btn1 = new JButton("LogIn");

                                con.add(btn1);

                }

}

OUTPUT:




*******************************************************

//buttonclick_event

//ActionListener and actionPerformed



import java.awt.*;

import java.awt.event.*;

import javax.swing.*;



//<applet code = "buttonclick_event.class" width = 500 height = 500></applet>



public class buttonclick_event extends JApplet implements ActionListener

{

                Container con;

                JLabel lbl1;

                JTextField txt1;

                JButton btn1;



                public void init()

                {

                                con = getContentPane();

                                con.setLayout(new FlowLayout());



                                lbl1 = new JLabel("Name");

                                con.add(lbl1);



                                txt1 = new JTextField(10);

                                con.add(txt1);



                                btn1 = new JButton("Click");

                                btn1.addActionListener(this);

                                con.add(btn1);

                }

                public void actionPerformed(ActionEvent ae)

                {

                                String nm = txt1.getText();



                                JOptionPane.showMessageDialog(this, " welocme " + nm);

                }

}

OUTPUT:







*******************************************************

// calculate square and cube using java swing.
import java.awt.*;
import java.awt.event.*;
import javax.swing.*;

 //<applet code = "calculate_sq_cu.java" width = 500 height = 500></applet>

public class calculate_sq_cu extends JApplet implements ActionListener
{
Container con;
JLabel lbl1, lbl2, lbl3;
JTextField txt1, txt2, txt3;
JButton btn1;

public void init()
{
con = getContentPane();
con.setLayout(new FlowLayout());

lbl1 = new JLabel("Enter Number");
con.add(lbl1);

txt1 = new JTextField(5);
con.add(txt1);

lbl2 = new JLabel("Square");
con.add(lbl2);

txt2 = new JTextField(5);
txt2.setEditable(false);
con.add(txt2);

lbl3 = new JLabel("Cube");
con.add(lbl3);

txt3 = new JTextField(5);
txt3.setEditable(false);
con.add(txt3);

btn1 = new JButton("Answer");
btn1.addActionListener(this);
con.add(btn1);


}
public void actionPerformed(ActionEvent ae)
{
int n = Integer.parseInt(txt1.getText());

int sq = n * n;
int cu = n * n * n;

txt2.setText(sq + "");
txt3.setText(cu + "");
}

}
OUTPUT:


*******************************************************


//calculate Arithmetic operation.
//ActionListener interface and ActionEvent

import java.awt.*;
import java.awt.event.*;
import javax.swing.*;

 //<applet code = "calculate_arithmetic_operation" width = 500 height = 500></applet>
public class calculate_arithmetic_operation extends JApplet implements ActionListener
{
Container con;
JLabel lbl1, lbl2, lbl3;
JTextField txt1, txt2, txt3;
JButton btn1, btn2, btn3, btn4;

public void init()
{
con = getContentPane();
con.setLayout(new FlowLayout());

lbl1 = new JLabel("Number1:");
con.add(lbl1);

txt1 = new JTextField(5);
con.add(txt1);

lbl2 = new JLabel("Number2:");
con.add(lbl2);

txt2 = new JTextField(5) ;
con.add(txt2);

lbl3 = new JLabel("Answer : ");
con.add(lbl3);

txt3 = new JTextField(5);
con.add(txt3);

btn1 = new JButton(" + ");
btn1.addActionListener(this);
con.add(btn1);

btn2 = new JButton(" - ");
btn2.addActionListener(this);
con.add(btn2);

btn3 = new JButton(" * ");
btn3.addActionListener(this);
    con.add(btn3);

btn4 = new JButton(" / ");
btn4.addActionListener(this);
con.add(btn4);
}
public void actionPerformed(ActionEvent ae)
{
int a = Integer.parseInt(txt1.getText());
int b = Integer.parseInt(txt2.getText());

int c = 0;

if (ae.getSource() == btn1)
c = a + b;
if (ae.getSource() == btn2)
c = a - b;
if (ae.getSource() == btn3)
c = a * b;
if (ae.getSource() == btn4)
c = a / b;
txt3.setText(c + "");
}
}
OUTPUT:



*******************************************************
//JcheckBox class
//ItemListener interface and ItemEvent class

import java.awt.*;
import java.awt.event.*;
import javax.swing.*;

//<applet code = "jcheckbox_class" width = 500 height = 500></applet>

public class jcheckbox_class extends JApplet implements ItemListener
{
Container con;
JCheckBox chk1, chk2, chk3;
JLabel lbl1;

public void init()
{
con = getContentPane();
con.setLayout(new FlowLayout());

chk1 = new JCheckBox(" Reading ");
chk1.addItemListener(this);
con.add(chk1);

chk2 = new JCheckBox(" Writing ");
chk2.addItemListener(this);
con.add(chk2);

chk3 = new JCheckBox(" Watching ");
chk3.addItemListener(this);
con.add(chk3);

lbl1 = new JLabel("                   ");
con.add(lbl1);

}
public void itemStateChanged(ItemEvent ie)
{
String msg = "";

if (chk1.isSelected() == true)
msg += chk1.getLabel();
if (chk2.isSelected())
msg += chk2.getLabel();
if (chk3.isSelected())
msg += chk3.getLabel();
lbl1.setText(msg);
}
}
OUTPUT:


*******************************************************
//JPassword

import java.awt.*;
import java.awt.event.*;
import javax.swing.*;

//<applet code = "jpassword_class" width = 500 height = 500></applet>

public class
 extends JApplet implements ActionListener
{
Container con;
JLabel lbl1, lbl2;
JTextField txt1;
JPasswordField p1;
JButton btn1;

public void init()
{
con = getContentPane();
con.setLayout(new FlowLayout());

lbl1 = new JLabel("Admin : ");
con.add(lbl1);

txt1 = new JTextField(10);
con.add(txt1);

lbl2 = new JLabel("Password : ");
con.add(lbl2);

p1 = new JPasswordField(10);
con.add(p1);

btn1 = new JButton("Log In");
btn1.addActionListener(this);
con.add(btn1);
}
public void actionPerformed(ActionEvent ae)
{
String user = txt1.getText();
String pass = p1.getText();

if (user.equals("Admin")) {
if (pass.equals("Admin")) {
JOptionPane.showMessageDialog(this, " welcome " + user);
}
else
{
JOptionPane.showMessageDialog(this, " Invalid Password ");

}
}
else
{
JOptionPane.showMessageDialog(this, " Invalid Username ");
}
}
}
OUTPUT:


*******************************************************
        /*****************
        *                  *
* Layout Manager    *
        *  *
        ******************/

//Flow Layout
 import java.awt.*;
 import javax.swing.*;

 //<applet code = "flowlayout.class" width = 500 height = 500></applet>

 public class flowlayout extends JApplet
 {
  Container con;
  JLabel lbl1, lbl2;
  JTextField txt1;
  JPasswordField pass1;

  public void init()
  {
  con = getContentPane();
  con.setLayout(new FlowLayout(FlowLayout.LEFT));

  lbl1 = new JLabel("User");
con.add(lbl1);

txt1 = new JTextField(10);
con.add(txt1);

lbl2 = new JLabel("Password");
con.add(lbl2);

pass1 = new JPasswordField(10);
con.add(pass1);
  }
 }
OUTPUT:



*******************************************************
//Border Layout

import java.awt.*;
import javax.swing.*;

//<applet code = "borederlayout.class" width = 500 height = 500></applet>

public class borederlayout extends JApplet
{
Container con;
JButton b1, b2, b3, b4, b5;

public void  init()
{
con = getContentPane();
con.setLayout(new BorderLayout(5, 5));

b1 = new JButton("North");
con.add(b1, "North");

b2 = new JButton("West");
con.add(b2, "West");

b3 = new JButton("East");
con.add(b3, "East");

b4 = new JButton("South");
con.add(b4, "South");

b5 = new JButton("Center");
con.add(b5, "Center");
}
public Insets getINSETS()
{
return new Insets(20, 20, 20, 20);
}
}
OUTPUT:


*******************************************************
//no Layout

import java.awt.*;
import javax.swing.*;

/*<applet code = "nolayout" width = 500
 height = 500></applet>
*/

 public class nolayout extends JApplet
 {
  Container con;
  JLabel lbl1, lbl2;
  JTextField txt1, txt2;
  JButton btn1;

  public void init()
  {
  con = getContentPane();
  con.setLayout(null);

  lbl1 = new JLabel("username");
  lbl1.setBounds(20, 20, 80, 20);
  con.add(lbl1);

  txt1 = new JTextField(10);
  txt1.setBounds(90, 25, 100, 20);
  con.add(txt1);

  lbl2 = new JLabel("username");
  lbl2.setBounds(20, 20, 80, 20);
  con.add(lbl2);

  txt2 = new JTextField(10);
  txt2.setBounds(90, 25, 100, 20);
  con.add(txt2);

  btn1 = new JButton("Login");
  btn1.setBounds(70, 80, 80, 30);
  con.add(btn1);
  }
 }
OUTPUT:


*******************************************************
//GridLayout

import java.awt.*;
import javax.swing.*;

/*<applet code = "gridlayout" width = 500
 height = 500></applet>
*/

 public class gridlayout extends JApplet
 {
  Container con;
  JButton btn[] = new JButton[6];

  public void init()
  {
  con = getContentPane();
  con.setLayout(new GridLayout(3, 2, 5, 5));
  for (int i = 0; i < 6; i++ ) {
  btn[i] = new JButton("Button - " + i);
  con.add(btn[i]);
  }
  }
 }
OUTPUT:

*******************************************************
//BoxLayout

import java.awt.*;
import javax.swing.*;

/*<applet code = "boxlayout" width = 500
 height = 500></applet>
*/

 public class boxlayout extends JApplet
 {
  Container con;
JButton b1, b2, b3;

public void  init()
{
con = getContentPane();
con.setLayout(new BoxLayout(con, BoxLayout.LINE_AXIS));

b1 = new JButton("Button -1");
con.add(b1);

b2 = new JButton("Button -2");
con.add(b2);

b3 = new JButton("Button -3");
con.add(b3);
}
 }
OUTPUT:


*******************************************************
//BoxLayout

import java.awt.*;
import javax.swing.*;

/*<applet code = "boxlayout_PAGE_AXIS" width = 500
 height = 500></applet>
*/

 public class boxlayout_PAGE_AXIS extends JApplet
 {
  Container con;
JButton b1, b2, b3;

public void  init()
{
con = getContentPane();
con.setLayout(new BoxLayout(con, BoxLayout.PAGE_AXIS));

b1 = new JButton("Button -1");
con.add(b1);

b2 = new JButton("Button -2");
con.add(b2);

b3 = new JButton("Button -3");
con.add(b3);
}
 }
OUTPUT:


*******************************************************
//JComboBox
import java.awt.*;
import java.awt.event.*;
import javax.swing.*;

/*<applet code = "jcombobox" width = 500
 height = 500></applet>
*/

 public class jcombobox extends JApplet implements ItemListener
 {
  Container con;
  JComboBox cmb;
  JLabel lbl1;

  public void init()
  {
  con = getContentPane();
  con.setLayout(new FlowLayout());

  cmb = new JComboBox();

  cmb.addItem("Aapdu Junagadh");
  cmb.addItem("Dev Bhumi Dwarka");
  cmb.addItem("Somnath");
  cmb.addItem("kutch");
  cmb.addItem("Rangilu Rajkot");
  cmb.addItemListener(this);
  con.add(cmb);


lbl1 = new JLabel("                   ");
con.add(lbl1);
  }
  public void itemStateChanged(ItemEvent ie)
  {
  lbl1.setText(cmb.getSelectedItem().toString());
  }
 }
OUTPUT:


*******************************************************
//JList

import java.awt.*;
import javax.swing.*;
import javax.swing.event.*;

/*<applet code = "jlist" width = 500
 height = 500></applet>
*/

public class jlist extends JApplet implements ListSelectionListener
{
Container con;
JList list1;
JTextField txt1;
JScrollPane scrollpane;

String str[] = {"12", "14", "16", "18", "20", "22", "24",
"26", "28", "30", "32", "34" ,"36"};

public void init()
{
con = getContentPane();
con.setLayout(null);

txt1 = new JTextField(5);
txt1.setBounds(80, 10, 50, 20);
con.add(txt1);

list1 = new JList(str);
list1.addListSelectionListener(this);

scrollpane = new JScrollPane(list1);
scrollpane.setBounds(80, 30, 50, 100);
con.add(scrollpane);
}
public void valueChanged(ListSelectionEvent ie)
{
txt1.setText(list1.getSelectedValue().toString());
}
}
OUTPUT:


*******************************************************
//JRadioButton Buttongroup
//ActionListener interface and ActionEvent class

import java.awt.*;
import java.awt.event.*;
import javax.swing.*;

//<applet code = "JRadioButton_Buttongroup" width = 500 height = 500></applet>

public class JRadioButton_Buttongroup extends JApplet implements ActionListener
{
Container con;
JRadioButton r1, r2, r3;
ButtonGroup bg;
JLabel lbl1;

public void init()
{
con = getContentPane();
con.setLayout(new FlowLayout());

bg = new ButtonGroup();

r1 = new JRadioButton("Male");
r1.addActionListener(this);
bg.add(r1);
con.add(r1);

r2 = new JRadioButton("Female");
r2.addActionListener(this);
bg.add(r2);
con.add(r2);

r3 = new JRadioButton("Other");
r3.addActionListener(this);
bg.add(r3);
con.add(r3);

lbl1 = new JLabel("        ");
con.add(lbl1);
}
public void actionPerformed(ActionEvent ae)
{
String msg = "";
if (r1.isSelected()  == true)
lbl1.setText(r1.getLabel());
else if (r2.isSelected())
lbl1.setText(r2.getLabel());
else if (r3.isSelected())
lbl1.setText(r3.getLabel());
}
}
OUTPUT:


*******************************************************
//JPanel class
 import java.awt.*;
 import javax.swing.*;

 /*
 <applet code = "jpanel_class" width = 500
 height = 500></applet>
 */

 public class jpanel_class extends JApplet
 {
  Container con;
  JPanel p1, p2;
  JRadioButton r1, r2, r3, r4;
  JCheckBox chk1, chk2, chk3;
  ButtonGroup bg;

  public void init()
  {
  con = getContentPane();
  con.setLayout(new GridLayout(1, 2));

  p1 = new JPanel();
  p1.setLayout(new GridLayout(3, 1));
  chk1 = new JCheckBox("Reading");
  p1.add(chk1);
  chk2 = new JCheckBox("Writng");
  p1.add(chk2);
  chk3 = new JCheckBox("Playing");
  p1.add(chk3);

  p2 = new JPanel();
  p2.setLayout(new GridLayout(4,1));

  bg = new ButtonGroup();

  r1 = new JRadioButton("SC");
  bg.add(r1);
  p2.add(r1);
  r2 = new JRadioButton("ST");
  bg.add(r2);
  p2.add(r2);
  r3 = new JRadioButton("OBC");
  bg.add(r3);
  p2.add(r3);
  r4 = new JRadioButton("Other");
  bg.add(r4);
  p2.add(r4);

  con.add(p1);
  con.add(p2);
  }
 }
OUTPUT:


*******************************************************
//CardLayout

import java.awt.*;
import java.awt.event.*;
import javax.swing.*;

/*
<applet code = "cardlayout" width = 200
height = 200></applet
*/
public class cardlayout extends JApplet implements ItemListener
{
Container con;
JPanel p1, p2, p3, p4;
JButton b1, b2, b3;
JLabel lbl1, lbl2, lbl3;

CardLayout card;
JComboBox cmb;

String Items[] = {"ButtonPanel", "Labelpanel"};

public void init()
{
con = getContentPane();
con.setLayout(new BorderLayout());

p1 = new JPanel();
p1.setLayout(new FlowLayout());

b1 = new JButton("Button - 1");
p1.add(b1);
b2 = new JButton("Button - 2");
p1.add(b2);
b3 = new JButton("Button - 3");
p1.add(b3);

p2 = new JPanel();
p2.setLayout(new FlowLayout());

lbl1 = new JLabel("Label - 1");
p2.add(lbl1);
lbl2 = new JLabel("Label - 2");
p2.add(lbl2);
lbl3 = new JLabel("Label - 3");
p2.add(lbl3);

p3 = new JPanel();
p3.setLayout(new FlowLayout());
cmb = new JComboBox(Items);
cmb.addItemListener(this);
p3.add(cmb);

card = new CardLayout();
p4 = new JPanel();
p4.setLayout(card);
p4.add(p1, "ButtonPanel");
p4.add(p2, "Labelpanel");

con.add(p3, "North");
con.add(p4, "South");
}
public void itemStateChanged(ItemEvent ie)
{
CardLayout c = (CardLayout) p4.getLayout();
c.show(p4, cmb.getSelectedItem().toString());
}
}
OUTPUT:



*******************************************************
//GroupLayout

import java.awt.*;
import javax.swing.*;

//<applet code = "grouplayout.class" width = 400
// height = 300></applet>

public class grouplayout extends JApplet
{
Container con;
JLabel lbl1;
JButton btn1;
GroupLayout group;

public void init()
{
con = getContentPane();
group = new GroupLayout(con);
con.setLayout(group);

lbl1 = new JLabel("Click Button =>");

btn1 = new JButton("Click");


group.setHorizontalGroup(
group.createSequentialGroup()
.addComponent(lbl1)
.addGap(10,20,30)
.addComponent(btn1)
);

group.setVerticalGroup(
group.createParallelGroup(
GroupLayout.Alignment.BASELINE)
.addComponent(lbl1)
.addComponent(btn1)
);
}
}
OUTPUT:


*******************************************************
//SpringLayout class
import java.awt.*;
import javax.swing.*;

/*<applet code = "springclass"
width = 100 height = 100></applet>*/

public class springclass extends JApplet
{
Container con;
JLabel lbl1;
JTextField txt1;
SpringLayout spring;

public void init()
{
con = getContentPane();
spring = new SpringLayout();
con.setLayout(spring);

lbl1 = new JLabel("Username");
txt1 = new JTextField(10);

con.add(lbl1);
con.add(txt1);

spring.putConstraint(SpringLayout.WEST,lbl1,10,
SpringLayout.WEST, con);
spring.putConstraint(SpringLayout.NORTH,lbl1,10,
SpringLayout.NORTH, con);

spring.putConstraint(SpringLayout.WEST,txt1,10,
SpringLayout.EAST, lbl1);
spring.putConstraint(SpringLayout.NORTH, txt1, 10,
SpringLayout.NORTH, con);

spring.putConstraint(SpringLayout.EAST, con, 10,
SpringLayout.EAST, txt1);
spring.putConstraint(SpringLayout.SOUTH, con, 10,
SpringLayout.SOUTH, txt1);
}
}
OUTPUT:


*******************************************************
//GridBagLayout class

import java.awt.*;
import javax.swing.*;

/*
<applet  code = "gridbaglayout" width = 300
 height = 200></applet>
*/

 public class gridbaglayout extends JApplet
 {
  Container con;
  JButton b1, b2, b3, b4, b5;
    GridBagLayout grid;
    GridBagConstraints gbc;

    public void init()
    {
    grid = new GridBagLayout();
    con = getContentPane();
    con.setLayout(grid);
    gbc = new GridBagConstraints();

    b1 = new JButton("First");
    b2 = new JButton("Second");
    b3 = new JButton("Third");
    b4 = new JButton("Fourth");
    b5 = new JButton("Five");

    gbc.fill = GridBagConstraints.HORIZONTAL;
    gbc.gridx = 0;
    gbc.gridy = 0;
    con.add(b1, gbc);


    gbc.gridx = 1;
    gbc.gridy = 0;
    con.add(b2, gbc);

    gbc.fill = GridBagConstraints.HORIZONTAL;
    gbc.ipady = 20;
    gbc.gridx = 0;
    gbc.gridy = 1;
    con.add(b3, gbc);

    gbc.gridx = 1;
    gbc.gridy = 1;
    con.add(b4, gbc);

    gbc.fill = GridBagConstraints.HORIZONTAL;
    gbc.gridx = 0;
    gbc.gridy = 2;
    gbc.gridwidth = 2;
    con.add(b5, gbc);

    }
 }
OUTPUT:


*******************************************************








Comments

Post a Comment

Popular posts from this blog

7.Write a program to read a list containing item name, item code and cost interactively and produce a three-column output as shown below. NAME CODE COST Turbo C++ 1001 250.95 C Primer 905 95.70 ------------- ------- ---------- ------------- ------- ---------- Note that the name and code are left-justified and the cost is right-justified with a precision of two digits. Trailing zeros are shown.

 /*J_4_P_8 Write a program to read a list containing item name, item code and cost interactively and produce a three-column output as shown below. NAME                CODE      COST ======================= Turbo C++        1001          250.95 C Primer              905           95.70 ------------- ------- ----------------- ------------- ------- ----------------- Note that the name and code are left-justified and the cost is right-justified with a precision of two digits. Trailing zeros are shown. */ #include <iostream.h> #include <iomanip.h> #include <string.h> #include <conio.h> class item {         char name[40];         int code;         float cost; public:         void get_data(char *n, int c, float co)...
Read more

Quetion 6 : Consider the "in-order-issue/in-order-completion" execution sequence shown in f In Figure Decode OWE Execute 12 12 12 14 16 13 16 13 15 15 16 Write 024/06/02 11 3 4 11 12 13 13 N 15 16 a. Identify the most likely reason why I could not enter the execute fourth cycle. stage until the [2] b. Will "in-order issue/out-of-order completion" or "out-of-order issue/out-of-order completion" fix this? If so, which? Explain

Answer:   a. Identify the most likely reason why I could not enter the execute stage until the fourth cycle. One likely reason an instruction couldn't enter the execute stage until the fourth cycle is due to data hazards or resource conflicts: 1. Data Hazards: If the instruction depends on the result of a previous instruction that hasn't completed yet, it cannot proceed to the execute stage. This is often referred to as a Read After Write (RAW) hazard. 2. Resource Conflicts: If the required functional unit for execution (e.g., an ALU) is occupied by another instruction, the instruction will have to wait until the resource becomes available. b. Will "in-order issue/out-of-order completion" or "out-of-order issue/out-of-order completion" fix this? If so, which? Explain In-order issue/out-of-order completion  might help if the problem is related to instructions that can complete earlier being delayed by instructions that take longer to execute. This allows the...
Read more

8.odd and even number using if else.

 import java.util.*; class oddeven { public static void main(String arg[]) { Scanner obj = new Scanner(System.in); int no; System.out.print("Enter any no. : "); no = obj.nextInt(); if(no % 2 == 0) System.out.println(no + " is Even number"); else System.out.println(no + " is Odd number"); } }
Read more
